Performance Profile
|
Compensated Flow Range
|
1000 to 3000 ml/min, ± 5% (5 to 500 ml/min requires low flow accessories; see Low Flow Kit) Requires 1/4-inch ID tubing |
||||||||||||||||||||||||||||||||||||
|
Flow Control
|
Patented (U.S. Patent No. 6,741,056) system holds constant flow to ± 5% of the set-point | ||||||||||||||||||||||||||||||||||||
|
Compensation Range for a Minimum of 8-hour Operation
|
1000 ml/min at 30 inches water back pressure 2000 ml/min at 20 inches water back pressure 3000 ml/min at 10 inches water back pressure |
||||||||||||||||||||||||||||||||||||
|
Typical Back Pressure of Sampling Media (inches water)
Compare the information in this table to pump compensation range to determine appropriate applications. |
|||||||||||||||||||||||||||||||||||||
|
Temperature Range
|
Operating: 32 to 104 F (0 to 40 C) Storage: -4 to 113 F (-20 to 45 C)Protect sample pump from weather when in use outdoors. |
||||||||||||||||||||||||||||||||||||
|
Compensated Temperature Range
|
41 to 122 F (5 to 50 C ) | ||||||||||||||||||||||||||||||||||||
|
Operating Humidity
|
0 to 95% non-condensing | ||||||||||||||||||||||||||||||||||||
|
Power
|
Three standard AA alkaline batteries Rechargeable AA-size 1.2-volt NiMH batteries may be used but will provide approximately half the run time stated for disposable batteries. |
||||||||||||||||||||||||||||||||||||
|
LED Functions
|
Slow flash = normal run Fast flash = flow fault Double flash = low battery, approximately one-hour run time remaining Flash every eight seconds = pump shutdown due to exhausted batteries Indication of pump shutdown due to exhausted batteries will override all other indicators. Four flashes every six seconds = pump shutdown due to flow fault |
||||||||||||||||||||||||||||||||||||
|
Run Time
(new batteries) |
8.5 hours at 1 L/min, 25 inches water back pressure 10 hours at 2.5 L/min, 15 inches water back pressureDependent on batteries used. See tables below. |
||||||||||||||||||||||||||||||||||||
| Tubing | Requires 1/4-inch ID tubing | ||||||||||||||||||||||||||||||||||||
|
Case
|
Plastic, RFI/EMI-shielded, CE marked | ||||||||||||||||||||||||||||||||||||
|
Dimensions
|
4.6 x 3 x 1.75 in (11.7 x 7.6 x 4.4 cm) includes inlet and belt clip | ||||||||||||||||||||||||||||||||||||
|
Weight
(includes batteries) |
12 oz (340 gm) | ||||||||||||||||||||||||||||||||||||
|
Caution:
|
Do not operate AirLite in hazardous or explosive locations. AirLite is designed for applications that do not require intrinsic safety. | ||||||||||||||||||||||||||||||||||||
