P-511 Conductivity Meter

Measure conductivity, TDS, salinity and resistivity of water solutions, suitable for industrial and mining factories, water treatment engineering and environmental protection, especially for outdoor use.

Main Features:
●Large LCD screen with controllable white backlight.
●Built-in microprocessor chip with functions of auto calibration, auto temperature compensation, data storage, function setup, self-diagnosis, auto power off, low voltage display.
●Auto recognition of 8 standard conductivity solutions and there are two series of standard buffers for option: USA series, China series.
●Adopt advanced conductivity measurement technology, one point calibration of conductivity electrode can meet the measuring accuracy requirements for test 0.5μ S/cm ~ 200mS/cm.
●Able to switch between conductivity, TDS, salinity and resistivity. Multinomial calculation for TDS and salinity to ensure the conversion precision of the full scale.
●Conductivity mode has the function of non-linear temperature compensation for high purity water.
●Humanized designs like rack and skid proof shell make it more convenient for users.
● Plastic conductivity electrode with automatic temperature compensation to ensure fast and accurate result.
● Grade IP57 and provide optional carrying case.

Specifications

Conductivity

Measuring range

Conductivity: (0.00~19.99) μS/cm (20.0~199.9) μS/cm (200~1999) μS/cm

(2.00~19.99) mS/cm (20.0~199.9) mS/cm

TDS: (0 ~ 100) g/L

Salinity: (0~100) ppt

Resistivity: (0 ~ 100)MΩ·cm

Resolution

0.01/0.1/1μS/cm   0.01/0.1 mS/cm

 Accuracy

Electrode: ±1.0% FS

Instrument: ±1.5%FS

Temperature compensation

(0~100)℃(automatic)

Electrode constants

0.1/1/10 cm-1

Reference temperature

25℃, 20℃,18℃

Others

Data storage

200 sets

Storage contents

Series number, measuring value, measuring unit and temperature

Power

Two AA batteries(1.5V)

Size & Weight

160×90×30mm/360g (instrument)

480×300×60mm/1KG (with packing)

Working Conditions

Ambient temperature

(5~35)℃

Ambient humidity

≤85%

IP grade

IP57

Standard Configuration

1. P-511 Conductivity meter                                                   1 unit

2. Conductivity electrode                                                        1 pc

3. Backup AA battery                                                              2 pcs

5. Operation manual                                                               1 copy
