Specifications
| Motor/Pump: | PM10-5300AFC: Brushless, Electronic Control/3-Stage. PM10-5200AFC: Brushless, Electronic Control/2-Stage. PM10-4300AFC: Brushless, Electronic Control/3-Stage. PM10-4200AFC: Brushless, Electronic Control/2-Stage. PM10-3300BRL: Brushless, Mechanical Control/3-Stage. PM10-3000BRL: Brushless, Mechanical Control/2 Stage. PM10-2000: Brushed, Mechanical Control/2-Stage. |
| Housing | Anodized Aluminum Outdoor Shelter with lockable control panel door. See HI-Q’s HVP-2000 & PM10-HEAD for overall cabinet & Size Selective Inlet dimensions. |
| Calibrated Flow Range: | 10-50 CFM (CMM unit calibration upon request). NIST Traceable Calibration. |
| Unit Net Weight: | ~50 lbs. Cabinet Weight (avg.). 44 lbs. Size Selective Inlet. 20” x 20” x 50” @ 58 lbs. Cabinet Carton (avg.). 32” x 32” x 26” @ 52 lbs. Size Selective Inlet Carton. |
| Shipping Weight & Dimensions: | 20” x 20” x 50” @ 58 lbs. Cabinet Carton (avg.). 32” x 32” x 26” @ 52 lbs. Size Selective Inlet Carton. |
| PM10-3-Stage Power Specifications: | 115 VAC, 50/60 Hz.,10 Amp, 800 Watt 230 VAC, 50/60 Hz., 10.5 Amp, 1200 Watt |
| PM10-2-Stage Power Specifications: | 115 VAC, 50/60Hz., 5.0 Amp, 250 Watt 230 VAC, 50/60Hz., 5.0 Amp, 400 Watt |
| PM10-2000 Power Specifications: | 115 VAC, 50/60Hz., 9.0 Amp, 300 Air Watts 230 VAC, 50/60Hz., 4.6 Amp, 269 Air Watts |
| Elapsed Timer: (all units) | Electronic, Resettable Hours & Tenths of Hours, LCD read out, 5 year internal battery. |
| Flow Totalizer: (PM10-4300& 4200 only) | Resettable Standard Cubic Feet (total volume in cubic meters or liters upon request) |
| Flow Display: (PM10-4300 & 4200 only) | Standard Cubic Feet per Minute (SCCM or SLPM display upon request) |
| Flow Calibrator: | See Air Flow Calibrators |
| Filter Media: | See Filter Media For Air Sampling Section |
| Optional Equipment: | See “Options” listed above & Air Sampling Accessories |
